Ultimate Multi-Tap Rhythm Delay Unit With Flexible Control
Product Features
-
The ultimate multi-tap rhythm delay unit gives you quality TC Electronic delays you can control in three different ways to suit your creative needs
-
Stellar suite of delays provides you with an amazing creative palette, including classic TC delays ported from the 2290
-
Straight delay mode gives you absolute repeat control so you can sculpt phenomenal sounds with precision and ease
-
Novel rhythm mode lets you tap out a rhythm pattern and tempo for your delay right on the front of the unit
-
Up to 10 seconds of delay gives you lots of room for impact
-
Comes with 50 factory presets and has space to store 100 user presets
-
True 24-bit A/D and D/A converters for high-quality analog-to-digital conversion
-
Provides 1/4" TRS analog I/O and a 24-bit S/PDIF* digital I/O for 44.1 or 48 kHz sample rates
-
Spatial effect lets you add more width to the sound of your material
-
Filter offers you a softer, warmer, and more natural-sounding delay
-
Reverse delay mode lets you add a backwards delay
-
Dynamic delay ducking function listens to what you play and turns the delay up or down accordingly
-
Designed and engineered in Denmark
Heralded Heritage
Think of delays and chances are our delays are what you hear in your head. Not to toot our own horn (though we’d probably never leave the house again if we could), but our delays are the best out there - end of story. With D-TWO we wanted to combine our awesome delays with fun - we’ve added the truly musical Rhythm Tap feature: Not only tempo, but actual rhythm patterns can be tapped directly on the unit for results that are sure to quickly whip your creativity to new highs!
• TC quality delays and effects
• Multitap rhythm delay
• Absolute repeat control
TC Quality. ‘Nuff Said.
We’re not into repeating ourselves - we like to let our delays do that. They sound great and D-TWO houses some cool chorus effects and some sweet filters. All the TC classics are here from a Ping Pong to a Reverse delay, all ported straight from our 2290.
Terrifically Tappable
D-TWO offers 3 ways to control your delays: ‘traditional’, which is the setup used by every delay unit since the dawn of mankind, ‘straight’ which allows you to control the exact number of repeats and ‘rhythm mode’ which allows you to tap a tempo.
Control Your Repeats
Absolute repeat control is a nifty feature that allows you to do exactly what you thought it did when you read it: absolutely control your repeats. It’s great for sculpting some awesome sounds with precision and ease.
Specification
DIGITAL INPUTS AND OUTPUTS
| Connectors |
RCA Phono (S/PDIF) |
| Formats |
S/PDIF (24 bit), EIAJ CP-340, IEC 958 |
| Output Dither |
HPF/TPDF dither 24/20/16/8 bit |
| Sample Rates |
44.1 kHz, 48 kHz |
| Processing Delay |
0.1 ms @ 48 kHz |
| Frequency Response DIO |
DC to 23.9 kHz ± 0.01 dB @ 48 kHz |
ANALOG INPUTS
| Connectors |
1/4" phone jack, balanced |
| Impedance, bal/unbal |
21 kOhm / 13 kOhm |
| Max. Input Level |
+24 dBu |
| Min. Input Level for 0 dBFS |
0 dBu |
| Sensitivity @ 12 dB headroom |
-12 dBu to +12 dBu |
| A to D Conversion |
24 bit, 128 x oversampling bitstream |
| A to D Delay |
0.65 ms / 0.70 ms @ 48 kHz / 44.1 kHz |
| Dynamic Range |
100 dB typ, 20 Hz - 20 kHz |
| THD |
typ < 92 dB (0,0025 %) @ 1 kHz |
| Frequency Response |
+0/-0.1 dB @ 48 kHz, 20 Hz to 20 kHz |
| Crosstalk |
<-95 dB, 20 Hz to 20 kHz |
Analog Outputs
| Connectors |
1/4" phone jack, balanced |
| Impedance bal/unbal |
40 Ohm |
| Max. Output Level |
+20 dBu (balanced) |
| Output Ranges |
Balanced: 20/14/8/2 dBu Unbalanced: 14/8/2 dBu |
| D to A Conversion |
24 bit, 128 x oversampling bitstream |
| D to A Delay |
0.63 ms / 0.68 ms @ 48 kHz / 44.1 kHz |
| Dynamic Range |
104 dB typ, 20 Hz to 20 kHz |
| THD |
typ <-94 dB (0.002 %) @ 1 kHz, +20 dBu Output |
| Frequency Response |
+0/-0.5 dB @ 48 kHz, 20 Hz to 20 kHz |
| Crosstalk |
<-100 dB, 20 Hz to 20 kHz |
EMC
| Complies with |
EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B |
SAFETY
| Certified to |
IEC 65, EN 60065, UL6500 and CSA E65 |
ENVIRONMENT
| Operating Temperature |
32° F to 122° F (0° C to 50° C) |
| Storage Temperature |
-22° F to 167° F (-30° C to 70° C) |
| Humidity |
Max. 90 % non-condensing |
CONTROL INTERFACE
| MIDI |
In/Out/Thru: 5 Pin DIN |
| Pedal |
1/4" phone jack |
GENERAL
| Finish |
Anodized aluminum front, Plated and painted steel chassis |
| Display |
23 character / 280 icon STN-LCD display |
| Dimensions |
19" x 1.75" x 8.2" (483 x 44 x 195 mm) |
| Weight |
4.1 lb. (1.85 kg) |
| Mains Voltage |
100 to 240 VAC, 50 to 60 Hz (auto-select) |
| Power Consumption |
<15 W |
D-TWO
